Safety Light Curtain Parallel Beam GSL-1240 Greatselec

Safety Light Curtain Parallel Beam GSL-1240 Greatselec

Product Details:

  • Product Type Curtain Parallel Beam
  • Usage Industrial
  • Click to view more
X

Price And Quantity

  • 1 , , Unit

Product Specifications

  • Curtain Parallel Beam
  • Industrial

Trade Information

  • 7-10 Days

Product Description

SPECIFICATIONS:-

  • Power 12-24 volts DC
  • Supply protection Reverse polarity protected
  • output PNP or NPN/ NC
  • Output indications Through LEDs
  • Channel indication Led indication for each channel
  • Response time On to off:10-15 m sec.off to on:50-100 m sec.
  • No of beams 6,8,10,12,16,18,24,30,36
  • Beam by pass Provided in all model
  • Protected height 100mm-1500mm
  • Pitch offered 20, 30,40, 50, 90mm
  • Adjustable Range Up to 3 meters
  • (Higher range up to 5,10,15 mtr. available)
  • Standard Cable length 5 meters for emitter, 3 meters for receiver
  • Operating Temperature Up to 55 Degrees centigrade
  • Cross Section 50X36 mm
